36W Up And Down IP65 Waterproof LED Emergency Wall Light

36W Up And Down IP65 Waterproof LED Emergency Wall Light uses Aluminum Tube Body and Safty Glass Diffuser.Citizen COB and Stable Emergency Driver keeps the top quality and long life 50000 hours to meet safety lighting solution. CRI92 Color Index and good design reflector provides a beautiful UP and Down lighting performance to exterior wall, outdoor walkways and other architectural building areas.

>>Model:ILED-BH-090

>>Inventory: 500+ pcs In Stock

>>Categories: >> Decorative LED Lighting» Outdoor LED Wall Light
Contact Now

CLICK HERE TO SEND INQUIRY


Wechat-iLeds

Description

Order Code

Installation

Application

36W Up And Down IP65 Waterproof  LED Emergency Wall Light Key Parameters

Model

Wattage

Lumen

Dimensions

ILED-BH-075

3W x 2

6000LM

φ64xH160mm

ILED-BH-080

6W x 2

1200LM

φ90xH260mm

ILED-BH-085

9W x 2

1800LM

φ108xH300mm

ILED-BH-090

18W x 2

3600LM

φ145xH300mm

ILED-BH-095

24W x 2

4800LM

φ160xH450mm



Input

110-265VAC or 110-277VAC

LED Source

Citizen COB

Lumen Output

100LM/W

Size

φ145xH300mm

Materials

Aluminum+ tempered glass

PF

>0.9

CCT

2800-6500K

CRI

>90

Electrical Classification

Class I

IP Class

IP65

Beam Angel

30°,  60° or 90°

Body Color

Black

Gray

Warranty

3-5 years

Certifications

SAA,CE,RoHS



36W Up And Down IP65 Waterproof  LED Emergency Wall LightPackage Detail

Net Weight

Quantites /Carton

Carton Size

Gross Weight/Carton

1.68KGs

8 pcs

64x54x34cm

18.2KGS



36W Up And Down IP65 Waterproof  LED Emergency Wall Light Application

Widely Providing lighting to walkways, hotels, wall mounted areas, building decorative lighting,step lighting, exterior outside enviroments etc.


36W Up And Down IP65 Waterproof LED Emergency Wall Light
36W Up And Down IP65 Waterproof  LED Emergency Wall Light
36W Up And Down IP65 Waterproof LED Emergency Wall Light
36W Up And Down IP65 Waterproof  LED Emergency Wall Light
36W Up And Down IP65 Waterproof LED Emergency Wall Light
36W Up And Down IP65 Waterproof  LED Emergency Wall Light
36W Up And Down IP65 Waterproof LED Emergency Wall Light
36W Up And Down IP65 Waterproof  LED Emergency Wall Light

Color Temperature and Color of Body will be as the Postfix of all code.

CCT: 3000K – 3K / 4000K – 4K / 5000K -5K / 6000K-6K

Color Finished:  Black Painted – BL / Gray Painted / GR

Standard CCT and Color Finished:  Black  Painted, 3000K.



For example:

Normal, 4000K, Black Painted , the detail code is

ILED-BH-085-4KBL



2x18W 36W IP65 Up&Down DALi LED Wall Light Order Items

Item NO.

Function Detail

MOQ

ILED-BH-090

Normal

100 pieces

ILED-BH-090-PIR

On/Off PIR Sensor

100 pieces

ILED-BH-090-EM

Emergency Maintained

100 pieces

ILED-BH-090-DALI

DALI Dimmable

100 pieces

ILED-BH-090-DIM

Triac Dimmable

100 pieces

ILED-BH-090-DM10

0-10V Dimmable

100 pieces
