DALI Triac 0-10V Dimmable LED Oyster Plafondi Ceiling Light

DALI Triac 0-10V Dimmable LED Oyster Plafondi Ceiling Light 18W / 24W can be perfect to work with DALI System, and the dimmable lighting is very good, not flick, adopt LM80 LED source,CRI>80,PF>0.9, high lumen output 90~95LM / W for commercial lighting, and also a good option to replace traditional 2D Lighting Fitting, also approved CE, RoHS, SAA and TUV.

>>Model:ILED-OL-A(XX)

>>Inventory: 500+ pcs In Stock

>>Categories: >> Commercial LED Lights» LED Bulkhead Light
Contact Now

CLICK HERE TO SEND INQUIRY


Wechat-iLeds

Description

Order Code

Installation

Application

DALI Triac 0-10V Dimmable LED Oyster Plafondi Ceiling Light  Key Data:

Model

Wattage

Lumen Output

Dimensions

ILED-OL-A18W-DALI

18W

1600LM (90~95LM / W)

Ф326x98mm

ILED-OL-A24W-DALI

24W

2100LM (90~95LM / W)

Ф395x113mm



DALI Triac 0-10V Dimmable LED Oyster Plafondi Ceiling Light  Other Parameters

Input

85-110VAC or 220V~240VAC

LED Source

LM80 LEDs

Materials

Steel Plate + PMMA

PF

>0.9

CCT

2800-7000K

CRI

>80

Electrical Classification

 Class I

IP Class

 IP21

Beam angle

120°

Body Color

White Painted or Silver

Warranty

3 years

Certification

CE&RoHS&SAA,TUV



DALI Triac 0-10V Dimmable LED Oyster Plafondi Ceiling Light  Package Information:

Model

Gross Weight / Piece

Inner Box Size

Quantities / Carton

Carton Size

Gross Weight / Carton

ILED-OL-A18W-DALI

1.28 KGS

335x335x110 mm

10 pieces

685x565x360mm

14.8 KGS

ILED-OL-A24W-DALI

2 KGS

415x415x120 mm

5 pieces

620x430x440mm

11 KGS



DALI Triac 0-10V Dimmable LED Oyster Plafondi Ceiling Light Application:
Widely used in Schools, Shops, Nursing Homes, Offices, Hospitals, Meeting Rooms, Hotels, Corridors, Warehouses, Toilets, etc.


Drawing 18W Light
Drawing 18W Light
Drawing 24W Light
Drawing 24W Light
Dimmable LED Oyster Light
Dimmable LED Oyster Light
Dimmable LED Oyster Light
Dimmable LED Oyster Light
Dimmable LED Oyster Light
Dimmable LED Oyster Light

Color Temperture and Color of Body will be as the Postfix of all code.

Iron Steel Housing Base – IS / Aluminum Housing Base - AL

CCT: 3000K – 3K / 4000K – 4K / 5000K -5K / 6000K-6K

Color Finished: White Painted – WH / Black Painted – BL / Stain Silver / SS

Standard CCT and Color Finished:  White  Painted, 4000K, Iron Steel Housing Base.

For example:

Iron Steel Housing Base, Normal, 4000K, White Painted , the detail code is

ILED-OL-A18W-IS-WH-4K



18W(Iron Steel Housing Base) Order Items

Item NO.

Function Detail

MOQ

ILED-OL-A18W-IS

Normal

100 pieces

ILED-OL-A18W-IS-MC

On/Off Motion Sensor

100 pieces

ILED-OL-A18W-IS-MLC

Dimmable Standby Sensor

100 pieces

ILED-OL-A18W-IS-EM

Emergency 3 Hours

100 pieces

ILED-OL-A18W-IS-EMS

Sensor + Emergency 3 Hours

100 pieces

ILED-OL-A18W-IS-MLEM

Dimmable Standby Sensor + Emergency 3 Hours

100 pieces

ILED-OL-A18W-IS-MLS

Mast Slave Motion Sensor

100 pieces

ILED-OL-A18W-IS-DALI

DALI Dimmable

100 pieces

ILED-OL-A18W-IS-DIM

Triac Dimmable

100 pieces

ILED-OL-A18W-IS-DM10

0-10V Dimmable

100 pieces

18W(Aluminum Housing Base) Order Items

Item NO.

Function Detail

MOQ

ILED-OL-A18W-AL

Normal

100 pieces

ILED-OL-A18W-AL-MC

On/Off Motion Sensor

100 pieces

ILED-OL-A18W-AL-MLC

Dimmable Standby Sensor

100 pieces

ILED-OL-A18W-AL-EM

Emergency 3 Hours

100 pieces

ILED-OL-A18W-AL-EMS

Sensor + Emergency 3 Hours

100 pieces

ILED-OL-A18W-AL-MLEM

Dimmable Standby Sensor + Emergency 3 Hours

100 pieces

ILED-OL-A18W-AL-MLS

Mast Slave Motion Sensor

100 pieces

ILED-OL-A18W-AL-DALI

DALI Dimmable

100 pieces

ILED-OL-A18W-AL-DIM

Triac Dimmable

100 pieces

ILED-OL-A18W-AL-DM10

0-10V Dimmable

100 pieces
