RGBW DMX LED Wall Washer Light Exterior IP67 Waterproof 24W 36W 48W
DMX512 RGBW Wall washer lights are lighting fixtures that “wash” a wall with light with RGBW in one LEDs and built-in DMX512 IC, rather than a focused beam of light. This indirect lighting is usually placed at the bottom of a wall or you can get wall mounted wall washer lights to cast a downward beam.. X4 LED Wall Washers Lights of iLed is designed with RGB+3000K LEDs with DMX512 controller which is perfect for feature lighting, providing an amazing colour wash effect to the outside or inside of buildings.They offer spectacular effects that ‘get the party going’ indoors in night clubs, bars, shows or events. Prestigious projects across the world building such as 5 Stars Hotel, Shopping Mall and Dubai Tower, have created impressive exteriors using X4 LED wall washers Lights from iLed.
Highlights
→ RGB+2000K-6000K
→ DMX512 Control
→ IP67 Waterproof
→ DC24V Safety Input
| Model | Wattage | Lumen Output | Dimensions |
| LED-WW-X4 24W | 24W | 1500LM | L1000mm*W28mm*H60mm |
| LED-WW-X4 36W | 36W | 2200LM | L1000mm*W36mm*H60mm |
| LED-WW-X4 48W | 48W | 3200LM | L1000mm*W36mm*H60mm |
| Input | DC 24V | LED Source | SMD3030 |
| Materials | Pure Aluminum
+ tempered glass
|
Pixels | 6 pcs LEDs as a Pixel |
| Wattage | 18W/36W/48W | Lumen Effective | 80LM/W |
| LEDs Colour | RGBW(2000K,3000K,
4000K,5000K,6000K)
|
Controller | DMX512 |
| Electrical Classification | Class III | IP Rating | IP67 |
| Beam Angel | 20°,30° or 60° | Body Color | Gray |
| Warranty | 3-5 years | Certifications | SAA CE ROHS |
Send Your Inquiry
1. Unmatched Precision and Performance: The ILED-WW-X4 offers exceptional precision in lighting effects, thanks to its four LEDs per pixel and customizable lens angles (20°, 30°, or 60°). This level of precision allows clients to achieve the desired lighting ambiance with unparalleled accuracy and control.
2. Versatile Color Options: With its RGB+W color capabilities, including a wide range of color temperatures (2000K, 3000K, 4000K, 5000K, and 6000K), the ILED-WW-X4 enables clients to create captivating lighting displays. The ability to choose from warm or cool tones enhances the versatility of this light, making it suitable for various applications and settings.
3. Durability and Aesthetic Appeal: Constructed with high-quality materials such as aluminum and tempered glass, the ILED-WW-X4 combines durability with an attractive design. Clients appreciate its robust build, ensuring long-lasting performance even in challenging environments.
4. Easy Integration and Programming: The ILED-WW-X4 features a DMX512 controller and an address code functionality that simplifies integration into existing lighting systems. Clients can easily program and configure the light, making installation and setup hassle-free.
5. Reliability and Protection: The ILED-WW-X4 incorporates double insulation waterproof filling treatment, ensuring protection against water vapor accumulation on the glass surface during use. Its overflow line protection and metal waterproof joint further enhance its reliability, offering peace of mind to clients.
6. Flexibility and Customization: With multiple wattage options (24W, 36W, and 48W), clients have the freedom to customize the brightness levels according to their specific requirements. This flexibility allows for tailored lighting solutions that meet the unique needs of different projects.
7. Exceptional Support: Clients appreciate the comprehensive support offered by the ILED-WW-X4’s manufacturer. The availability of a knowledgeable and responsive customer support team ensures that clients receive assistance during the initial setup, programming, and ongoing maintenance stages, guaranteeing a smooth and successful lighting experience.
Q1: What is the input voltage requirement for the ILED-WW-X4?
A1: The ILED-WW-X4 operates on a 24VDC input.
Q2: What materials are used in the construction of the ILED-WW-X4?
A2: The ILED-WW-X4 is made of aluminum and tempered glass, combining durability and aesthetic appeal.
Q3: What color options are available for the ILED-WW-X4?
A3: The ILED-WW-X4 offers RGB+W color options, including 2000K, 3000K, 4000K, 5000K, and 6000K.
Q4: What are the wattage options for the ILED-WW-X4?
A4: The ILED-WW-X4 is available in 24W, 36W, and 48W wattage options.
Q5: What lens angles are available for the ILED-WW-X4?
A5: The ILED-WW-X4 comes with lens angle options of 20°, 30°, or 60°, allowing for customized illumination patterns.
Q6: Does the ILED-WW-X4 have a built-in controller?
A6: Yes, the ILED-WW-X4 features a built-in DMX512 controller, enabling seamless integration into existing lighting systems.
Q7: How many LEDs are there per pixel in the ILED-WW-X4?
A7: The ILED-WW-X4 has four LEDs per pixel, ensuring precise and clear lighting effects.
Q8: How is the ILED-WW-X4 protected against water damage?
A8: The ILED-WW-X4 incorporates double insulation waterproof filling treatment, preventing water vapor accumulation on the glass surface during use.
Q9: What type of connector cable does the ILED-WW-X4 use?
A9: The ILED-WW-X4 utilizes a VDE M18 waterproof connector cable, providing easy and secure connections.
Q10: Is the ILED-WW-X4 easy to program and configure?
A10: Yes, the ILED-WW-X4 features an address code functionality that allows for easy programming and configuration, simplifying the setup process.
Q11: Does the ILED-WW-X4 offer reliable performance and protection?
A11: Absolutely. The ILED-WW-X4 is designed with overflow line protection, ensuring durability and safeguarding against potential electrical issues.
Q12: Does the ILED-WW-X4 provide uniform and consistent lighting?
A12: Yes, the ILED-WW-X4 offers luminous uniformity and good color consistency, ensuring an even and balanced lighting experience.
Q13: Is customer support available for the ILED-WW-X4?
A13: Yes, we provide comprehensive customer support for the ILED-WW-X4, assisting with initial setup, programming, and ongoing maintenance to ensure a successful lighting experience
X5 DMX512 RGBW LED Wall Washer Lights are commonly used in architectural lighting, stage productions, concerts, clubs, and events where vibrant color-changing lighting effects are desired. With their ability to produce a wide range of colors and the flexibility of DMX512 control, these lights can create stunning and dynamic lighting displays on building facades, highlighting architectural details, and creating immersive atmospheres. They are also popular in stage and entertainment settings, allowing for synchronized color changes and effects that enhance performances and create captivating visual experiences for the audience.
DMX512 RGBW LED Wall Washer Lights Application
LED Wall Washer Light for Landscape Lighting
1. How to Write the address code for this DMX512 LED Wall Washer Light?
You can visit our youtube link which teaches you how to write the address code one by one.
2. How to Connect the cables with DMX controller?
You can visit our youtube link which teaches you how to connect the cables with DMX512 one by one.
3. Performance Efficiency: Clients prioritize energy efficiency and seek lighting solutions that offer optimal performance while minimizing power consumption. The ILED-WW-X4’s use of a 24VDC input and various wattage options (24W, 36W, and 48W) allows clients to select the appropriate power level for their specific requirements, ensuring efficient operation and reduced energy costs.
You can visit our youtube link which showes you what effective of DMX 512 RGBW LED Wall Washer Light after writing the address codes.
4. Longevity and Durability: ILED-WW-X4’s construction with high-quality materials such as aluminum and tempered glass ensures durability and longevity, providing clients with a reliable lighting solution that can withstand the test of time.
5. Customization and Flexibility: ILED-WW-X4 offers customization options such as lens angles (20°, 30°, or 60°) and a wide range of color temperatures (2000K, 3000K, 4000K, 5000K, and 6000K). This level of customization allows clients to tailor the lighting effects to suit their desired ambiance and meet the unique demands of their projects.
6. Reliability and Support: ILED-WW-X4’s overflow line protection, address code functionality for easy programming, and comprehensive customer support all contribute to a sense of reliability and assurance. Clients can rest assured knowing that they have access to assistance and guidance throughout the installation, programming, and maintenance processes.
